AUTOMATIC BVM PORTABLE VENTILATOR

EASY, SMART, EFFICIENT FUNCTION & DESIGN _ OXIVI

SPECIFICATION:

• SIZE : 340 x 150 x 160(mm)
• WEIGHT : OXIVI 2,045(g) Adaptor 165(g)
• POWER INPUT : AC 100~240V / 50-60 Hz / 1.5A Max
• Li-ion battery : Lithium-ion (3.6V * 3 cells)
• POWER OUTPUT : DC 12V 3.5A

FEATURES:

• THE TIDAL VOLUME AND RPM (RESPIRATORY RATE PER MINUTE) IS ADJUSTABLE
• INHALATION AND EXHALATION RATE IS 1:2 TO PROVIDE COMFORTABLE BREATHING
• THE POWER OUTPUT IS 12 VOLT 3.5A (12V 3.5A)
• LITHIUM ION BATTERY IS EQUIPPED FOR OUTDOOR USE AND CONVENIENT MOBILITY
• THE STRUCTURE OF THE PRODUCT IS SIMPLE FOR ITS DURABILITY
• EASY TO OPERATE FOR ANY NEW USER

MATERIAL:

• Body (ABS, PC)
• Upper cover (ABS, PC)
• Front Assist Cover (ABS, PC)
• Crank (Composite PC)
• Spades (Sressed Plate, acetal)
• Spade Cover (ABS, PC)
• BODY BAFT (Stenle steels)
• Air Flow Control Panel (ABS, PC)
• Motor Deceleration (7k)
• Bearing (688 etc.)
• LED Instrument Panel (Temperature, Humidity, Hours of Use, Time Control)

HOW TO USE

• Make sure to place the BVM bag on the debossed platform under the cover.
• Connect the adapter to OXIVI and press the power button.
• Set up OXIVI according to the user’s condition.
• Monitor user’s condition and OXIVI regularly for user’s safety
